BVC IV40

Designed for dry-only pickup or wet and dry, these versions of the INDY IV40 are bagless and collect directly into the tank. The Wet and Dry version has a drain for easy emptying. Standard filtration is a heavy-duty needlefelt filter bag. The WorD version has a filter mesh. Optional coated filters are available. A HEPA option can also be fitted.

The powerful turbine is designed for long-life. A wide range of tools and hoses are available in both 38mm and 51mm sizes. IV40 uses a 51-38mm reducer. Standard hose ends and inlets are metal for durability. IV40D and WorD are fitted with a reverse-air filter cleaning system, and can also be used to blow air by repositioning the hose to the exhaust. The unit can be supplied with or without the optional trolley. Both 110v and 230v units are available.

click for larger image

The ATEXD22 versions of the BVC IV40 are suitable for ATEX ZONE 22 rated areas. These units differ from the other models in the IV40 range in that they use a brushless motor design, eliminating spark risk, complemented by ATEX rated components. The separated cooling air for the motor is protected by HEPA filters in the head of the machine on both the inlet and outlet side of the motor. Main filtration is 3 stage; firstly a disposable microfibre bag, followed by an ATEX rated needlefelt main filter complemented by the third stage HEPA working air filter.

This unit is available as a standard ATEX rated unit or, additionally, certified as H Class and issued with an appropriate DOP test certificate. MOD approved under JSP403 for use in indoor firing ranges for cleaning up both lead dust and any propellant residue. Available in both 110v and 230v versions, with or without the optional trolley.

The M-Class and H-Class versions differ from the standard IV40D in that the collection tank has a low-level inlet with protective screw cap, and the tank is designed to be used with the disposable K4 microfibre collection bag. These versions are fitted with a vacuum gauge indicating when suction is reduced because the bag is full and/or there is a blockage.

All units are fitted with a large HEPA filter. The M-Class units are designed for all duties where an M-Class is specified. The H-Class units in addition are supplied with DOP test certification. The IV40DM and IV40DH are designed to be used with the conductive hose and tool sets. All units are available with or without the optional trolley. Both 110v and 230v units are available.
